How to test LED outdoor products with a constant temperature and humidity chamber?

The following procedures need to be carried out in order to test LED outdoor goods using a chamber with a constant temperature and humidity:

  1. Make sure the chamber is ready: Before commencing the test, make sure the temperature and humidity levels are at the levels you want them to be and give the chamber some time to settle down.
  2. Install the LED product: When installing the LED product in the chamber, make sure that it is fastened firmly and that all of the necessary electrical connections have been established.
  3. Establish a connection with the testing apparatus: Establish a connection between the testing apparatus, such as a spectroradiometer or a photometer, and the LED product
  4. Carry out the test: To get started with the test, measure the light output and color accuracy of the LED product at a variety of various temperatures and degrees of humidity. To guarantee the accuracy and reliability of the data, you should carry out several measurements at a variety of time intervals.
  5. Analyze the findings: The results of the tests need to be analyzed in order to establish whether or not the LED product satisfies the necessary standards and requirements. This may include comparing the findings to the standards set by the industry or the specifications provided by the manufacturer.
  6. Keep a record of the results: The results of the tests should be documented in a report, which should contain the levels of temperature and humidity, the testing equipment used, as well as the findings of the measurements.

In order to guarantee that the findings are correct and can be relied upon, it is essential to carry out the test in a setting that can be carefully monitored and using testing equipment that has been appropriately calibrated. A stable environment for testing is provided by the chamber that maintains a constant temperature and humidity. This eliminates the influence of external variables that might interfere with the findings of the test.
